●ATEX Compliant 55-JSB Series has been added. [New]
●A clamp connection type and a butt weld connection type have been added. [New]
●Low pressure loss due to angle seat structure!
●Long service life: 10 million cycles (Air, Water), 3 million cycles (Steam)
●Large flow rate
  A large flow rate is possible due to the optimized flow channel shape.
  (Cv factor: approx. 2.5 times)
●Compact: Height 166 mm (Port size: 1")
●All-in-One (Stainless steel 316L equivalent)
  Air, Water, Steam

Specifications

Valve SizeSeries 30
Valve TypeN.C./Standard Pressure Type
Body MaterialStainless Steel
Seal MaterialFluororesin
Port Size3/4
Pipe Thread TypeRc
Actuator Section SizeBore Size Φ50
Actuator Section MaterialStainless Steel

Datasheet (PDF)

SKU JSB31-ST20AR-3S
Brand SMC
