1/4" BSP Brass Normally Closed Solenoid Valve 0~10 Bar 240v AC FKM

Image illustration only

B55-2-3-1V - 1/4" BSP Port - 240V AC - 0-10 Bar

Model Port Size BSP Orifice ømm                         CV   Pressure (BAR)                                    Coil Specifications
B55-2-3-1V 1/4" 3                      0.26 0 to 10 SC-C1
14.4 Watts
15 Volt Amps
Class H Insulation

  • 2 way Direct Acting Normally Closed (power to open) Solenoid Valve
  • Brass Body, FKM seat
  • -10°C to 100°C Temperature Range
  • Comes with Coil & LED DIN Plug (IP65)
  • Install in any orientation (upright if possible)

Brass direct acting solenoid valve

Model                     G (BSP)                                      A                                          B                                           C                                                       H                             Weight Kg
B55-2-3-*V     1/4"  41      19 86.5 10.5 0.45



SKU B55-2-3-1-1V
Shipping Weight 5.0000kg
