Clamping module

EV-15/63-4

13290





GTIN: 4052568009144

Clamping surface
15x63
Stroke
4 mm

Technical Data

  • Stroke4 mm
  • Clamping surface15x63
  • Mounting positionoptional
  • Mode of operationSingle-acting
  • Symbol00991208
  • Operating pressure0.2 MPa ... 0.6 MPa
  • Operating pressure2 bar ... 6 bar
  • Operating pressure29 psi ... 87 psi
  • Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
  • LABS (PWIS) conformityVDMA24364-B1/B2-L
  • Suitability for the production of Li-ion batteriesMetals with more than 5% by mass of copper are excluded from use. Exceptions are printed circuit boards, cables, electrical plug connectors and coils.
  • Ambient temperature-20 °C ... 40 °C
  • Product weight65 g
  • Type of mountingWith through-hole
  • Pneumatic connectionM5
  • Material housingDie-cast aluminium
  • Material membraneTPE-U(PU)



SKU 13290
Brand FESTO
Shipping Weight 1.0000kg
Shipping Width 0.080m
Shipping Height 0.200m
Shipping Length 0.200m
