●Modular design with uniform body style
●Better visibility & environmental resistance
●2-layer construction: The bowl is covered with a transparent bowl guard!
  Better visibility: 360°
●No tools are required.
  Easier replacement of the element (AF-D only)
●Attachments:
  Spacer: Y200-D, Y300-D, Y400-D, Y500-D, Y600-D
  Spacer with bracket: Y200T-D, Y300T-D, Y400T-D, Y500T-D, Y600T-D

Specifications

Body Size30
Pipe Thread TypeRc
Port Size1/4
Float Type Auto DrainWithout Auto Drain
Pressure GaugeWithout Pressure Gauge
Digital Pressure SwitchWithout Digital Pressure Switch
The Pressure Relief 3 Port ValveWithout The Pressure Relief 3 Port Valve
Set Pressure0.05 To 0.85 Mpa Setting
Bowl/Lubricant Exhaust PortPolycarbonate Bowl,Lubricator Without Drain Cock
Drain Port Option aWith Drain Cock
Exhaust MechanismRelieving Type
Flow DirectionFlow Direction:Left To Right
Drain Port Option bDrain Cock Without Barb Fitting (For Φ6 X Φ4 Nylon Tube)
Unit RepresentationUnit On Product Label:MPa,°C,Pressure Gauge In SI Units:MPa

Datasheet (PDF)

SKU AC30A-02-D
Brand SMC
