Product Lifecycle Information



Product is planned to be discontinued. Do not use for new designs.




01/2027 - Product is being phased out. Do not use for new designs.




11/2028 - Product is discontinued. Products for replacement may be available while stocks permit.




12/2028 - Product is discontinued.

Branching module

FRM-H-D-MAXI

170689





GTIN: 4052568074449

Standard nominal flow rate in main flow direction 1->2
13500 l/min
Operating pressure
0.25 bar - 16 bar



Technical Data

  • Mounting positionAny
  • DesignBranching module
  • Symbol00991511
  • Operating pressure0.025 MPa ... 1.6 MPa
  • Operating pressure0.25 bar ... 16 bar
  • Standard nominal flow rate in main flow direction 1->213500 l/min
  • Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-] Inert gas
  • Corrosion resistance class CRC2 - Moderate corrosion stress
  • LABS (PWIS) conformityVDMA24364-B1/B2-L
  • Storage temperature-10 °C ... 60 °C
  • Air purity class at outputCompressed air to ISO 8573-1:2010 [7:-:-] Inert gas
  • Media temperature-10 °C ... 60 °C
  • Ambient temperature-10 °C ... 60 °C
  • Product weight446 g
  • Pneumatic connection, port 3G3/4
  • Pneumatic connection, port 4G1/4
  • Note on materialsRoHS compliant
  • Material housingDie-cast zinc
SKU 170689
Brand FESTO
Shipping Weight 1.0000kg
Shipping Width 0.080m
Shipping Height 0.200m
Shipping Length 0.200m
