Solenoid coil

Solenoid coil (x10 pack)

MD-2-24VDC-PA

549903

Electrical connection
To DIN EN 175301-803
Type of mounting
Via knurled nut
Characteristic coil data
24 V DC: 6.8 W
Degree of protection
IP65

GTIN: 4052568051921

Technical Data

  • Mounting positionoptional
  • Duty cycle100%
  • Characteristic coil data24 V DC: 6.8 W
  • Permissible voltage fluctuations+/- 10 %
  • LABS (PWIS) conformityVDMA24364-B2-L
  • Degree of protectionIP65
  • Ambient temperature-20 °C ... 50 °C
  • Max. tightening torque for fitting0.5 Nm
  • Product weight110 g
  • Electrical connectionTo DIN EN 175301-803
  • Type of mountingVia knurled nut
  • Note on materialsRoHS-compliant
  • Material solenoid coilDuroplast Copper Steel
  • Material windingCopper

Downloads

VACS_EN.PDF

Technical data

Links

Spare parts



SKU 549903
Brand FESTO
Shipping Weight 1.0000kg
Shipping Width 0.080m
Shipping Height 0.200m
Shipping Length 0.200m
