Solenoid coil

MSFG-24-EX

536931





GTIN: 4052568049102

Electrical connection
3-pin - Plug pins with connection pattern to Festo standard for MSSD-F
Type of mounting
Via knurled nut
Characteristic coil data
24 V DC: 4.5 W
Degree of protection
IP65


Technical Data

  • Mounting positionoptional
  • Min. pick-up time10 ms
  • Duty cycle100%
  • Characteristic coil data24 V DC: 4.5 W
  • Permissible voltage fluctuations+/- 10 %
  • CE mark (see declaration of conformity)To EU Explosion Protection Directive (ATEX)
  • Explosion protection certification outside the EUEPL Dc (CN) EPL Gc (CN)
  • Explosion protectionZone 2 (ATEX) Zone 2 (CN) Zone 22 (ATEX) Zone 22 (CN)
  • ATEX category gasII 3G
  • ATEX category dustII 3D
  • Explosion ignition protection type for gasEx nA IIC T4 X Gc
  • Explosion ignition protection type for dustEx tc IIIC T130°C X Dc IP65
  • Explosion ambient temperature-5°C <= Ta <= +40°C
  • LABS (PWIS) conformityVDMA24364-B2-L
  • Degree of protectionIP65
  • Ambient temperature-5 °C ... 40 °C
  • Max. tightening torque for socket0.4 Nm
  • Product weight55 g
  • Electrical connection3-pin Plug pins with connection pattern to Festo standard for MSSD-F
  • Type of mountingVia knurled nut
  • Note on materialsRoHS-compliant
  • Material solenoid coilDuroplast Copper Steel
  • Material windingCopper
