Vacuum generator

Vacuum generator

VAD-1/8

14015

GTIN: 4052568002619



  • Nominal size, Laval nozzle0.8 mm
  • Mounting positionoptional
  • Ejector characteristicHigh vacuum
  • DesignT-shape
  • Symbol00991482
  • Operating pressure0.15 MPa ... 1 MPa
  • Operating pressure1.5 bar ... 10 bar
  • Operating pressure21.75 psi ... 145 psi
  • Max. vacuum80 %
  • Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
  • Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
  • LABS (PWIS) conformityVDMA24364-B1/B2-L
  • Media temperature-20 °C ... 80 °C
  • Ambient temperature-20 °C ... 80 °C
  • Type of mountingWith through-hole
  • Pneumatic connection, port 1G1/8
  • Pneumatic connection, port 3G1/8
  • Vacuum connectionG1/8
  • Material housingDie-cast aluminium

Downloads



VAD_VAK_EN.PDF

Technical data

Links

Spare parts





SKU 14015
Brand FESTO
Shipping Weight 1.0000kg
Shipping Width 0.080m
Shipping Height 0.200m
Shipping Length 0.200m
