Product Lifecycle Information




Product is planned to be discontinued. Do not use for new designs.



04/2026 - Product is being phased out. Do not use for new designs.




11/2028 - Product is discontinued. Products for replacement may be available while stocks permit.




12/2028 - Product is discontinued.

On/off valveHEP-1-D-MAXI

193260

GTIN: 4052568153335

Pneumatic connection, port 1
G1
Standard nominal flow rate (standardised to DIN 1343)
6500 l/min
Operating pressure
0 bar - 16 bar
Type of actuation
Pneumatic



Technical Data On/off valve HEP-1-D-MAXI

  • DesignPiston gate valve
  • Type of actuationPneumatic
  • Sealing principleSoft
  • Exhaust-air functionCannot be throttled
  • Manual overrideNone
  • Type of resetMechanical spring
  • Symbol00991173
  • Valve function3/2-way, single solenoid, closed
  • Operating pressure0 MPa ... 1.6 MPa
  • Operating pressure0 bar ... 16 bar
  • Pilot pressure3 bar ... 16 bar
  • C value27.6 l/sbar
  • b value0.32
  • Standard nominal flow rate (standardised to DIN 1343)6500 l/min
  • Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4] Inert gas
  • Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
  • Corrosion resistance class CRC2 - Moderate corrosion stress
  • Note on materialsRoHS compliant
  • LABS (PWIS) conformityVDMA24364-B1/B2-L
  • Media temperature-10 °C ... 60 °C
  • Ambient temperature-10 °C ... 60 °C
  • Type of mountingInline installation With accessories
  • Mounting positionAny
  • Flow directionNon-reversible
  • Product weight800 g
  • Pneumatic connection, port 1G1
  • Pneumatic connection, port 2G1
  • Pneumatic connection, port 3G3/8
  • Pilot air port 12G1/8
  • Air purity class at outputCompressed air to ISO 8573-1:2010 [7:4:4] Inert gas
  • Material sealsNBR
  • Material housingDie-cast aluminium
SKU 193260
Brand FESTO
Shipping Weight 1.0000kg
Shipping Width 0.080m
Shipping Height 0.200m
Shipping Length 0.200m
