Shock absorberYSRW-16-26

191197

GTIN: 4052568014896

Stroke
26 mm
Max. energy consumption per stroke
35 J
Cushioning
Self-adjusting - Soft characteristic curve



Technical Data Shock absorber YSRW-16-26

  • Size16
  • Stroke26 mm
  • CushioningSelf-adjusting Soft characteristic curve
  • Mounting positionAny
  • Position detectionNone
  • Symbol00991495
  • Max. impact speed3 m/s
  • Reset time at room temperature0.3 s
  • Reset time at min. ambient temperature1 s
  • Mode of operationPushing Single-acting
  • Corrosion resistance class CRC2 - Moderate corrosion stress
  • LABS (PWIS) conformityVDMA24364-B2-L
  • Ambient temperature-10 °C ... 80 °C
  • Cushioning length26 mm
  • Max. stop force2000 N
  • Max. energy consumption per stroke35 J
  • Max. energy consumption per hour68000 J
  • Max. residual energy0.16 J
  • Reset force6 N
  • Min. insertion force60 N
  • Product weight190 g
  • Load range50 kg
  • Type of mountingVia lock nut
  • Note on materialsRoHS compliant
  • Material sealsNBR
  • Material housingGalvanised steel
  • Material piston rodHigh-alloy steel



SKU 191197
Brand FESTO
Shipping Weight 1.0000kg
Shipping Width 0.080m
Shipping Height 0.200m
Shipping Length 0.200m
